Accessories (overview)
Motor holding brake control modules
Motor holding brake control module E94AZHY0101
8
467
EDS94SPP101 EN 10.2
Area Values
Input voltage DC 24 V (18 ... 30 V)
Output voltage Corresponds to input voltage
Brake current 0.3 ... 5 A
Switching capacity Max. 110 W
Breaking energy Max. 10 Ws
Cable protection Recommendation: 7.5 A, tripping characteristic "B" or "C"
Control input
Control voltage
Internal
Control current
Protective function
Maximum cable length In the chapter "Electrical installation" the dependency of the cable length on
the brake current and the cable cross−section is described.
Operating frequency Max. 6/min
Operating times Can be ignored compared to the delay time of the brake.
See documentation of the brake.
Service life > 10 millions of cycles
Protection against
Overload No
Short circuit of the
terminals
Yes
Polarity reversal at the
input
Yes
Insulation
1)
Double insulation (EN61800−5−1: V
rated
= 300 V AC),
Separation (UL: V
rated
= 500 V AC)
1)
Brake connection against control card of the controller
