Lenze L-force 9400

Accessories (overview)
Motor holding brake control modules
Motor holding brake control module E94AZHY0101
8

470
EDS94SPP101 EN 10.2
Connection plan
L1
L2
L3
N
PE
F10
BD1BD1
L1 L3 PEL2
+-
--
++
BD2BD2
M
3~
M
3~
E94APxE E94AxxEE94AxxE
E94AZHxxxxxE94AZHxxxxx
~
24 V DC
£ 1.5 mm²
0
"
"
"
"
E94AZH005
L1
L2
L3
N
PE
F10
BD1BD1
L1 L3 PEL2
+-
--
++
BD2BD2
M
3~
M
3~
~
24 V DC
£ 2.5 mm²
E94APxE E94AxxEE94AxxE
E94AZHxxxxxE94AZHxxxxx
"
"
"
"
E94AZH006
F10
Secondary cable protection. Observe the standards of the cable protection when selecting
the fuse!
 Use twin wire end ferrules.
 HF shield termination through large−surface PE connection
