Page 8
Bypass Switch-Universal Units Only
The bypass switch has two modes: Normal and Bypass. When the switch is set to
Bypass (red LED illuminated) the SCRs and relays are forced to turn on
independent of the control module.
Modules
The dimmer modules simply slide and plug in. No tools are required, except for a
shipping screw when dimmers are pre-installed at the factory.
To avoid misapplication of product, 277V cabinets are
mechanically keyed to reject 120V modules and the previous style of 277V
dimmer modules without integral breakers.
Checklist
Unpack the system
Report any damages to the freight carrier
Attach the flush or surface mounting hardware
Attach the cabinet to the wall
Terminate the main feed wiring
Termi nate the lo ad wi ring
Terminate control wiring
Verify the dimmer ballasts are correctly wired
Verify the main feed wiring
Verify the load wiring
Verify the remote control wiring
Verify the configuration of each module
