wiring for control stations should go to these terminals in the these
cabinets. These terminals are fed directly by the power supply and
accommodate larger wires and multiple wires per terminal section solving
power distribution problems for remote power controls.
Figure 20 - Control Station Power Wiring - Preferred Wiring Method
Testing the Wiring
To assure problem-free startup, it is important to check the system wiring for
proper connections, shorts and opens.
The following procedure is recommended:
Step 1: Test the following wire pairs for shorts at each station location, using
an ohmmeter or other continuity tester.
1-2 Open
2-3 Open
3-4 Open
Step 2: Repair any short circuits before continuing.
+24 VDC
COMMON
