Page 68
Specifications
Dimmer cabinet capacity 12 circuits, 15 or 20-amp each 24 circuits, 15 or 20-amp each
Dimensions with surface-mount
hardware
30.125" wide x 29.88" high x
4.125" deep
30.125" wide x 43" high x 4.125"
deep
Weight, fully loaded 125lb. 155 lb.
Conduit entry See Figure 4 See Figure 4
Maximum fan noise rating 41 dBA each 41 dBA each
Ambient operating temperature 32° F to 104° F32° F to 104° F
Maximum operating humidity 90% non-condensing 90% non-condensing
Input Feeder Configurations
120V 3φ Cabinets
120/208V 3φ, 80A Max
4 wire+Ground, 60Hz
120/208V 3φ, 175A Max
4 wire+Ground, 60Hz
Input Feeder Configurations
120V 1φ Cabinets
120/240V 1φ, 125A Max
3 wire+Ground, 60Hz
120/240V 1φ, 250A Max
3 wire+Ground, 60Hz
Input Feeder Configurations
277V 3φ Cabinets
277/480V 3φ, 80A Max
4 wire + Ground, 60Hz
277/480V 3φ, 175A Max
4 wire + Ground, 60Hz
Nominal 240 V circuits Not available
Phase to neutral operating voltage
120V Cabinets
110 to 130 V +/- 10%
Phase to neutral operating voltage,
277V Cabinets
277V +/- 10%
Operating frequency 47 - 63 Hz
Cabinet type NEMA type 1 for indoor use only; available for surface or flush mounting
Control inputs Luma-Net, DMX-512, 0 to +10 VDC (Optional Analog card)
Square law curve control Yes
Top, bottom, right side feed Yes
Fully plug-in dimmer modules Yes
Dimmers available for Incandescent, LV stepdown transformers, neon, cold cathode, high-rise
time, fluorescent dimmer ballasts, 0-10 VDC controlled ballasts, Mark X,
Hi-Lume, quartz, and constant circuits. Electronic Low Voltage is
supported with factory qualification of transformer.
Bypass switch for every dimmer 120V Dimmers Yes
Universal Dimmers: Yes
277V Dimmers optional, requires 277V constant module
Operating efficiency Minimum 97%
UL and cUL Listed Yes
Default SETUP Code (Password) 000
