Page 18
Step 3: Load Circuit Wiring - 120 Volt Units
Load and neutral terminal blocks accept the following wire sizes:
Table 6- Wire Combinations for Load and Neutral Block
Preferred wire entry is from the right hand side of the cabinet.
For all loads except Lutron’s Hi-Lume ®, Eco-10, Fluorescent dimming ballasts
and the Leviton High Rise Dimmer Module:
Figure 6 - Incandescent, Non-Dim and Constant Loads
Load Terminal (AWG) Neutral Block (AWG)
Quantity Size Quantity Size
1#81#4
1#101 #6
1-3 #12 1 #8
1-4 #14 1 #10
1#12
1#14
Black
White
SURFACE
MODULE
LOAD
12
11
10
22
24
23
20
21
19
SWITCHED
DIMMED
SWITCHED
DIMMED
SWITCHED
DIMMED
UPPER TERMINALS
LOWER TERMINALS
WRITABLE
LOAD
NEUTRAL WHITE
DIMMED HOT BLACK
DIMMED
HOTHOT
SWITCHED
NEUTRAL BLOCK
