Page 30
Figure 18- Luma-Net Termination Jumper
Figure 19- Luma-Net Termination Jumper Locations
The common (DCC) must be connected to earth ground at only one point
in the run. The dimmer cabinet or a Luma-Net Hub (if used) are the most
likely places.
Special Feature for Low Voltage Power Terminations
The 12 and 24 circuit dimming cabinets have a separate +24 VDC and
Common terminal strip. Since the Luma-Net connector will only accept 1
#12 wire, it may be necessary to pig tail the connections to a single wire
coming into the connector. To simplify this process, all power supply type
REM+
REM -
COM
TERM
N/C
+V
1
2
3
4
5
6
Termination Jumper
5
6
1
2
3
4
Phoenix Connector
D4200 CONTROL STATION
PRESET SELECT STATION
C
12
18
15
16
17
13
14
6
9
10
11
7
8
3
4
5
1
2
A
B
DMX
CANCEL
LUMANET
CLEAR
PHASELOSS
AUXILIARY
FULLBRIGHT
COMMUNICATIONPORTS
FAN
SAVE
FULL
SELECT
BRIGHT
A2000-D
Terminate Luma-Net
in these Locations
Ground Shield
at one point ONLY!
To Next Page
