Page 58
Step 13D: Modify the Dimmer Type Features:
Once you have assigned the module type, you can alter the default settings for
each dimmer type.
Features applicable to all dimmer types:
• Full Bright Input: Toggles On/Off override to Full Bright from the front
control panel
• External Full Bright: Toggles On/Off override to Full Bright from an external
contact.
• Input: Determines the control input source. Choices are:
•Scan All (A)
•EXT Full Bright
•Full Bright
•Analog
•Luma-Net
•DMX512
• DMX 512 Address: Sets the DMX address for that particular circuit (1-512)
• Luma-Net Address: Sets the Luma-Net address for that particular circuit (1-
2048)
• Dimmer Feedback: Toggles the Dimmer Feedback for Luma-Net on or off.
If multiple dimmer circuits have the same Luma-Net address, all
but one should have its Dimmer Feedback turned off.
• Max Level: Sets the max level a dimmer will reach (%). An "S" next to this
number indicates that it is using the default setting.
• Min Level: Sets the min. level a dimmer will reach (%). An "S" next to this
number indicates that it is using the default setting.
• Analog Input: Sets the Analog input number if applicable.
• Ph (Photocell): See step 13G
•
Features Specific to dimmer types:
Dimmer:
• Curve: Sets the dimmer curve. Choices are:
•Square Law
•Linear Volts
•Linear Lights
