Page 26
15 is less than the 40 available so all the components CAN BE wired on a single
run from the a-2000 24 Channel cabinet without an additional external power
supply.
Power Wire - Run Length
The maximum total run length of each segment is a function of the total number
of unit loads. A run becomes to long when the voltage drop, due to wire size and
run length, increase to a point where the station does not have sufficient voltage
to operate. The maximum run length, in feet, based on the total number of unit
loads is shown below:
Table 9 - Wire Size vs. Length of Runs - Power Wiring
Terminating the wiring
Control Stations can be located up to 2,000 ft. from the dimming cabinet.
The 2,000 ft. limitation is a RS485 digital communications specification.
The power supply pair must be sized correctly for the control stations that
are connected to them.
Luma-Net is wired Daisy Chained, station to station. For applications where runs
become too long a Luma-Net Hub can be used. See Figure 15 for the correct ways
to wire this system.
14 AWG (Feet) 12 AWG (Feet) 10 AWG Feet)
10 Unit Loads 1905 3000 4800
20 Unit Loads 950 1500 2400
30 Unit Loads 630 1000 1600
40 Unit Loads 475 750 1200
50 Unit Loads 380 600 960
60 Unit Loads 315 500 800
70 Unit Loads 270 425 685
80 Unit Loads 235 375 600
90 Unit Loads 210 330 530
100 Unit Loads 190 300 480
110 Unit Loads 170 270 435
120 Unit Loads 155 250 400
