Page 14
Main Feed and Load Wiring
Step 2: Power Wiring - Feed\Line Wiring
The entire right side of the dimmer cabinet is reserved for power wiring. Refer to
Figure 4 and the cabinet labels for all appropriate wiring notes. The cabinet
includes:
• Knockouts for feeding in and out through the top, bottom, or right side of the
cabinet.
• Main lugs for phases A, B, and C (or A and B in the case of a single-phase
cabinet (feed terminates to optional main breaker if provided).
• A load terminal block to land all the dimmer output load wiring.
• A multi-terminal neutral block.
• A single ground terminal.
Consult the factory if a multiple terminal ground bus is needed for your particular
installation.
Unless limited by an optional main breaker, the main lugs are sized for
every dimmer to be loaded to maximum capacity, however you may elect
to size the feed to the actual connected load on the cabinet.
