a-2000 User Guide
a-2000 Page 17
Dimmer Cabinets with Digital Controls
Revision G November 2006
Table 4 - Max Feeder and Wire Size, Cabinets with Main Breakers
Table 5 - Max Feeder and Wire Size, Cabinets with Main Lugs
Cabinets with Main Breakers (factory installed)
Main Breaker Size (A) Cabinet Sizes Wire Size
30, 50, 60 12, 24 #14-#2 AWG
40 24 #14-#2 AWG
70, 80, 100 12, 24 #12-2/0 AWG
90 24 #12-2/0 AWG
110, 125 24 #4-250kcmil
125 (1 phase only) 12 #4-250kcmil
150 24, 36 #4-250kcmil
175, 200 24, 36 #4-250kcmil
225 36 #4-250kcmil
Main Breaker not available 48 N/A
Cabinets with Main Lugs
Cabinet Size Phase Max Feed Size Wire Size
12 1 125A #14-#2 AWG
3 80A #14-#2 AWG
24 1 250A #6-250kcmil
3 250A #6-250kcmil
36 1 250A #4 - 250kcmil
3 175A #4 - 250kcmil
48 1 500A (2) #6-250kcmil
3 350A (2) #6-250kcmil
