Page 16
Note: Non Universal Cabinet pictured above
Figure 5 - Appropriate Wireways for High and Low Voltage Wires
Depending on the cabinet that was ordered, it will have either main lugs or a main
breaker. See Table 4-5 for feeder information. Information shown is for feeder
lugs only. If optional main breaker is installed, feeder information may be
reduced. Preferred entry is from the top or the top right hand side of the cabinet,
but may be run from the bottom as well.
Y
A
W
E
R
I
W
L
I
N
E
V
O
L
T
A
G
E
CLASS 2 WIRING
THIS AREA NOT AVAILABLE
FOR CABINET FEED WIRING
D
E
E
F
N
I
A
M
To Next Page
