Page 28
.
Table 10- Luma-Net Recommended Wire
Table 11 - Color Coding for Belden Wire
Figure 16 - Belden Wire Callouts
Manufacturer Catalog Number # of Pairs
Belden 9729, 9829 2
Belden 9841 1
Belden 88102 2 (Plenum Rated)
Alpha 6222C 1
Alpha 6412 1
Wire/Color No. Pair Pin/Terminal Pin/Function
Belden 9729
Red
Black
11
2
REM+
REM-
Red
White
2 N/C - Not Con-
nected
N/C - Not Con-
nected
N/C - Not Con-
nected
N/C - Not Con-
nected
Drains/Shields N/C - Not Con-
nected
See figure 17
Belden 9829
Blue with white stripe
White with blue stripe
11
2
REM+
REM-
Orange with white
stripe
White with orange
stripe
2 N/C - Not Con-
nected
N/C - Not Con-
nected
N/C - Not Con-
nected
N/C - Not Con-
nected
Drain/Shield N/C - Not Con-
nected
See figure 17
Drain/Shield
Drain/Shield
Belden 9729
Drain/Shield
Braid
Foil
Foil
Belden 9829
Black
Red
Black
White
Blue w/ White Stripe
White w/ Blue Stripe
Orange w/ White Stripe
White w/ Orange Stripe
