Dimmer Cabinets with Digital Controls
Revision G November 2006
Figure 30 - 42 Main Menu Screens
A2000 VER2.00 STATUS=OK 1PHASE A=121V B=123V 60 HZ
MENU SETUP ENTER SETUP CODE= 999
SETUP MENU SETUP MODULES?
MENU MODULE STATUS?
SETUP LUMANET START ADD=0001
MOD 01A= 00% DM INPUT= A
MODIFY SETUP CODE
SETUP MENU MODIFY DEFAULTS
SETUP DMX 512 START ADD=001
RESTORE FACTORY DEFAULTS
MODIFY DEFAULTS MIN LEVEL=000%
MODIFY DEFAULTS MAX LEVEL=100%
MODIFY DEFAULTS NONDIM O/F=040% MODIFY DEFAULTS MARK X O/F=002% MODIFY DEFAULTS MARK 7 O/F=002% MODIFY DEFAULTS LV MAG O/F=002% MODIFY DEFAULTS HILUME O/F=001% MODIFY DEFAULTS TUWR X O/F=002% LUMANET RESTORE ENABLE=NO MODIFY DEFAULTS LINE REG=OFF MODIFY DEFAULTS PHOTOCELL NONDIM MAX/MIN ENABLE=NO
ENTER NEW SETUP CODE= 565
SEE CHART ON NEXT PAGE FOR MENU'S
