Dimmer Cabinets with Digital Controls
Revision G November 2006
appropriate dimmer module type (see Appendix). In addition, some dimmer types
must be set up for specific dimmer types (functions) manually.
Table 15 - Available Dimmer Modules
Since the Dual Dimmer , Universal Dimmer, and High Rise Time Modules
can be used for load types other than an incandescent dimmer, you must
assign the particular module the functionality you wish it to use.
Below are the different type of dimmer functions:
• DM. A basic dimmer meant to drive incandescent lamps, quartz halogen lamps,
stepdown transformers for low voltage incandescent lamps, and neon or cold
cathode low power factor type transformers.
Module Catalog Number Description Automatically assigns Dimmer
Type-function to:
120 Volt Modules
000-A15DC-012 15 amp dual constant module N.A.
000-A15DD-012 15 amp dual dimmer module Dual-Dimmer (DM)
000-A15HD-012 15 amp high rise time (700
micro second) single channel
module
Single-Dimmer (DM)
000-A20DC-012 20 amp dual constant module N.A.
000-A20DD-012 20 amp dual dimmer module Dual-Dimmer (DM)
000-A20HD-012 20 amp high rise time (700
micro second) single channel
module
Single-Dimmer (DM)
000-A20UN-012 20 amp universal dual
dimmer module
Univers-Dimmer (DM)
120/277 Volt Modules
000-A20DD-A27 120/277 Volt dual dimmer
module
Dual-Dimmer (DM)
000-A20UN-027 120/277 universal dual
dimmer module
Univers-Dimmer (DM)
000-A20DC-A27 20A dual 120/277V constant
module
N.A.
