Dimmer Cabinets with Digital Controls
Revision G November 2006
Control Devices Unit
Load
@12VD
C
Unit
Load
@24VD
C
Station Type Unit
Load
@
12VDC
Unit
Load @
24VDC
D4200 LCD 5 2 Z-MAX Digital
Switch, 1 Button
N/A 0.6
D4200 Entry
(Button),
21Z-MAX Digital
Switch, 2 Buttons
N/A 0.8
D4200 Room
Combine Station
3 1 Z-AX Digital Switch,
3 Buttons
N/A 1.0
D4200 Remote I/R 2 1 Z-MAX Digital Sw.,
4 Buttons
N/A 1.1
Luma-Net Hub 6 3 Z-MAX Digital
Switch, 5 Button
N/A 1.3
D8000 LCD 3 2 Z-MAX Digital
Switch, 6 Button
N/A 1.0
D8000 Entry
(Button)
21Z-MAX Digital
Switch, 8 Button
N/A 1.1
D8000 Slider 2 1 Z-MAX Digital Sw.,
10 Button
N/A 1.3
D8000 Key switch 1 1 1 Button Low
Voltage Switch
N/A 0.6
D8000 I.O Port 2 1 2 Button Low
Voltage Switch
N/A 0.9
D8000 Combine/
Closure (Advanced)
11 10 3 Button Low
Voltage Switch
N/A 1.2
Infrared Only Occ
Sensor
N/A 1.2 4 Button Low
Voltage Switch
N/A 1.5
Ultrasonic Only Occ.
Sensor
N/A 1.2 5 Button Low
Voltage Switch
N/A 1.8
Multi-tech Occ
Sensor
N/A 1.2 6 Button Low
Voltage Switch
N/A 2.1
Ultrasonic 2-Way
Occ. Sensor
N/A 1.4 8 Button Low
Voltage Switch
N/A 2.7
Multi-tech 2-Way
Occ, Sensor
N/A 1.4 10 Button Low
Voltage Switch
N/A 3.3
Photocell, odc0p-
00w
Photocell, pcatr-000
Photocell, pcind-
000
-
