Menu item Description
Robust XON
On
Off
Determines whether or not the printer communicates availability to the computer
Notes:
• Off is the factory default setting.
• This menu item applies only to the serial port if Serial Protocol is set to
XON/XOFF.
Baud
1200
2400
4800
9600
19200
38400
57600
115200
138200
172800
230400
345600
Specifies the rate at which data can be received through the serial port
Notes:
• 9600 is the factory default setting.
• 138200, 172800, 230400, and 345600 baud rates are only displayed in the
Standard Serial menu. These settings do not appear in the Serial Option 1, Serial
Option 2, or Serial Option 3 menus.
Data Bits
7
8
Specifies the number of data bits that are sent in each transmission frame
Note: 8 is the factory default setting.
Parity
Even
Odd
None
Ignore
Sets the parity for serial input and output data frames
Note: None is the factory default setting.
Honor DSR
On
Off
Determines whether the printer uses the DSR Signal. DSR is a handshaking signal
used by most serial cables.
Notes:
• Off is the factory default setting.
• The serial port uses DSR to distinguish data sent by the computer from data
created by electrical noise in the serial cable. The electrical noise can cause stray
characters to print. Select On to prevent stray characters from printing.
Understanding printer menus
104
