Loading paper and specialty media
This section explains how to load the standard tray (Tray 1), also known as the 550-sheet tray, an optional 550-sheet
tray, an optional 2,000-sheet tray, a multipurpose feeder, and an optional 550-sheet specialty media drawer. It also
includes information about paper orientation, setting the Paper Size and Paper Type, and linking and unlinking trays.
Setting the paper size and type
1 Make sure that the printer is on and Ready appears.
2 From the printer control panel, press .
3 Press the up or down arrow button until
Paper Menu appears, and then press .
4 Press the up or down arrow button until
Paper Size/Type appears, and then press .
5 Press the up or down arrow button until the correct tray or feeder appears, and then press
.
6 Press the left or right arrow button until the correct size appears, and then press .
Paper Type appears.
7 Press the left or right arrow button until the correct type appears, and then press .
Submitting selection appears. The printer returns to the Paper Size/Type menu.
Loading the paper tray
The printer has up to five input sources to select from: the standard tray (Tray 1), also known as the 550-sheet tray,
an optional 550-sheet tray, an optional 2,000-sheet tray, a multipurpose feeder, and an optional 550-sheet specialty
media drawer. Load the paper or specialty media used for the majority of print jobs in Tray 1. Proper paper loading
prevents jams and facilitates trouble-free printing.
Note: The C736n, C736dn, and C736dtn model printers will support a total of four optional input sources. The C734n,
C734dn, C734dtn, and C734dnw model printers will support a total of three optional input sources.
Do not remove trays while a job prints or while Busy blinks on the printer control panel. Doing so may cause a jam.
1 Grasp the handle, and then pull the tray out. Remove the tray completely.
Loading paper and specialty media
54
