General information 1-1
4506-1xx
1. General information
The Lexmark™ E120 and E120n printers are monochrome laser printers designed for single users or small
workgroups.
Maintenance approach
The diagnostic information in this manual leads to the correct field replaceable unit (FRU) or part. Use the error
code charts, symptom index, and service checks to determine the symptom and repair the failure. See
“Diagnostic information” on page 2-1 for more information. See “Repair information” on page 4-1 for the
steps to replace FRUs. After completing the repair, perform tests as needed to verify the repair. See “Parts
catalog” on page 7-1 to help identify part numbers if parts need to be replaced
Models
There are two models:
Lexmark E120—ENA support, host-based printing in a Windows environment, an 8,000 page per month
maximum duty cycle (one time only), and a two button, two light operator panel.
Lexmark E120n—Built-in 10/100 BaseTX Ethernet, host-based printing in Windows (PCL) or Macintosh
(PostScript emulation) environment, a 10,000 page per month maximum duty cycle (one time only), and a
two button, six light operator panel.
The differences between the models are listed in the following table.
Overview of the printer
There are two available operator panels.
E120 operator panel
This model has two lights and two buttons. See “Diagnostics—E120” on page 2-2 for more information.
E120n operator panel
This model has six lights, two buttons, and an internal network adapter. See page “Diagnostics—E120n” on
page 2-8.
Item Lexmark E120 (4506-100) Lexmark E120n (4506-110)
Base memory 8MB 16MB
Maximum memory 8MB 16MB
Paper inputs Primary tray (tray 1), Priority feeder (manual feeder)
Emulations PCL PostScript emulation (Mac only), PCL, XL
Compatibility Windows Windows, Macintosh
Connectivity USB 2.0 USB 2.0, Ethernet
Photoconductor kit yield* 25,000 pages
* Photoconductor yield based on approximately 5% coverage of pages.
