25
Chapter 2: Features and Functions
Features and Functions
Rear View of Printer
Part Name Function
Parallel connector Connects the parallel cable.
Serial connector Connects the serial cable.
Tear-Off bar Allows you to tear off continuous forms.
Tractor connector Supplies power to the optional Tractor 2 Feeder.
Power connector Connects power from the power cord to the printer.
Power
Connector
Tractor Connector
Serial Connector
Tear-Off Bar
Parallel Connector
