Chapter 4: Selecting and Loading Paper
70
Selecting and Loading Paper
white lines.
Note: When the ribbon cartridge is installed and the top edge of the
paper is even with the top edge of the ribbon, the TOF is set to
one line, or 1/6 inch.
8
Press Store to save the position you want. SAVED appears on the
display for one second. The Ready light comes on solid.
Whenever you change the TOF setting, tear off excess continuous forms, then
unload and reload the paper by pressing Load/Unload. This ensures the
printer goes to the current tearoff setting.
Note: When Auto Tear-off is set to On, the paper advances to the current
tearoff position. If the tearoff position is not correct, see “Changing
Tearoff position” on page 72.
Setting TOF for Single Sheets and Envelopes
TOF can range from minus 2.54 cm (1 in.) to plus 55.88 cm (22 in.) from the
top of cut sheet paper. To set and save TOF:
1 Turn the printer On.
2
Make sure continuous forms are parked (press Load/Unload).
White lines
