Chapter 4: Selecting and Loading Paper
52
Selecting and Loading Paper
Loading a Single Sheet or Envelope
Single sheets or multi-part forms can be loaded one at a time into the manual
feed.
Note: If you have installed the optional Auto Sheet Feeder or Tractor 2
Feeder, see “Auto Sheet Feeder” on page 76 or “Tractor 2 Feeder” on
page 85 for paper loading instructions.
Loading a Single Sheet or Envelope into the Manual
Feed
1 Turn the printer On.
2
Make sure the paper path is clear.
If continuous forms are currently loaded, see “Loading a Single Sheet
or Envelope With Continuous Forms Already Loaded” on page 57.
3
Make sure AutoGap is set to On or Single AutoGap. For help, see
“Setting AutoGap” on page 44.
4 Move the paper select lever up to the single sheets position.
Continuous Forms
0.058-0.114 mm
(0.0023-0.0045 in.)
0.512 mm (0.0202 in.)
Envelopes
0.053 mm (0.021 in.)
Single Multiple part
To Next Page
