Chapter 5: Printer Options
Printer Options
The paper you use in the Auto Sheet Feeder must meet the following
specifications.
.
Installing the Auto Sheet Feeder
The Auto Sheet Feeder is easy to install and remove. You will not need to
make electrical connections or require special training or tools.
1 Make sure the printer is Off.
Automatic Feed Mode (Single-part Form)
Length 139.7 mm (5.5 in.) minimum
355.6 mm (14.0 in.) maximum
1
558.8 mm (22 in.)
2
Width 105 mm (4.13 in.) minimum
364 mm (14.3 in.) maximum
1
Paper width greater than 215.9 mm (8.5 in.).
2
For 215.9 mm (8.5 in.) paper width or less.
Manual Insertion Mode (Single-/Multi-part Form)
Length 139.7 mm (5.5 in.) minimum
355.6 mm (14.0 in.) maximum
1
558.8 mm (22 in.)
2
Width 76.2 mm (3.0 in.) minimum
420 mm (16.5 in.) maximum
Paper Weight
60 ~ 90 g/m
2
(16 ~ 24 lbs)
1
Paper width greater than 215. 9 mm (8.5 in.).
2
For 215.9 mm (8.5 in.) paper width or less.
