Lexmark Forms Printer 4227 Plus - Page 84

Chapter 5: Printer Options
78
Printer Options
2 Open, pull up, and remove the front cover.
3
Push up the paper select lever.
4 Insert the tabs on both sides of the Auto Sheet Feeder into the grooves
on the printer.
Front Cover
Paper Select Lever
Power Switch
Groove
Groove
Tab
Tab
