87
Chapter 5: Printer Options
Printer Options
6 Insert the tabs on both sides of the Tractor 2 Feeder into the grooves on
the printer.
7 Attach the front cover that came with the Tractor 2 Feeder.
8
Remove any cables attached to the back of the printer.
Groove
Tab
Right Side Panel
Left Side
Panel
Front Cover
