Lexmark T65 Series Product Study Guide

Lexmark T65x and X65x Mono Product Study Guide Rev 1.47
For Training Purposes Only 6/3/2009
35
Vertical Stripes (process direction)
CHECK THE MEDIA CONDITION
Load new, dry, recommended media and re-print the defective image.
CHECK THE MEDIA TRANSFER ROUTE (PAPER PATH)
Make certain it is free of debris or contamination.
CHECK THAT THE TRANSFER ROLL ASSEMBLY IS FREE OF EXCESS WEAR & CONTAMINATION.
CHECK THE PRINT CARTRIDGE FOR SPOTS OR OTHER DAMAGE ON THE DRUM SURFACE.
Make certain that it is free of excess wear or contamination.
CHECK THE HEAT ROLL AND PRESSURE ROLL
Remove the fuser unit assembly.
Is there contamination or cracks on the heat roll and/or
pressure roll? If so, replace the fuser unit assembly.
IF PROBLEM STILL PERSISTS; REPLACE THE SYSTEM CARD
CAUTION: : Allow the fuser unit
assembl
y
to cool down.
