300781172_002_C0 - 012/2019 - © Leybold 44
Options
10 Options
10.1 AC adaptor
10.1.1 Standard specification
Model SPU61A-108
Input voltage 90 - 264 Va.c.
Input current 1.45 A at 100 Va.c. maximum
Efficiency 88% at rated load
Frequency 47 - 63 Hz
Output voltage 24 V d.c.
Output current 2.5 A
Power requirement 60 W
Output variation ±3%
Ripple and noise (Vp-p ) 240 mVp-p
Protection Over-voltage, short-circuit protection, overload protection
Hold up time < 10 msec under maximum load, 110 Va.c.
Dimension L 118 x W 47 x H 30 mm
Weight 0.34 Kg
Operating temperature 0 - 70 °C
Operating humidity 0 - 95% (non-condensing)
Storage temperature -40 - 85 °C
Storage humidity 0 - 95% (non-condensing)
Reliability MTBF 100,000 hours minimum at maximum load, 25 °C
Applicable standard Safety standard: UL/c-UL (UL 60950-1: 2nd Edition),
TUV/GS (EN 60950-1: 2nd Edition), EMI: FCC class B,
EN 55022 and EN55024 class B, CE
