Description
15
300554859_002_C0 - 11/2016 - © Leybold
371
465
283
250
Ø 95
133
DN 63 ISO-K
DN 16 KF
MAINS (X20)
184
Fig. 1.7 Dimensional drawing TURBOLAB 90, dimensions in mm
Ø 95
DN 63 ISO-K
DN 16 KF
MAINS (X20)
DN 25 KF
238
1089
1285
104
480
580
238
133
Fig. 1.8 Dimensional drawing TURBOLAB 90 Cart, dimensions in mm
