Liebert AC4 User Manual

Function
Can be performed via: Where to find:
LCD
Service
Terminal
Instructions on
using function
Service Terminal
screen examples
Setup System Info x x
Setup System - Setup
System Info on
page52
Setup System Info
Change Password x x
Change Password on
page53
Change Password
Set Date & Time/Automatic Daylight Saving Time x x
Set Date &
Time/Automatic
Daylight Saving Time
on page53
Set Date &
Time/Automatic
Daylight Saving Time
Setup Site ID x x
Setup Site ID on
page54
Setup Site ID
Backup and Upload Configuration File — 4
Backup and Upload
Configuration File
(Service Terminal
Interface only) on
page54
Backup and Upload
Configuration File
(Service Terminal
Interface only)
Factory Defaults 4 4
Factory Defaults on
page57
Factory Defaults
Perform Firmware Update — x
Perform Firmware
Update (Service
Terminal Interface
only) on page57
Firmware Update
(Service Terminal
Interface only)
Setup Operation x x
Setup Operation on
page60
Setup Operation
Override Output x x
Override Output on
page64
Override Output
Clear Alarms & Logs x x Clear Alarms & Logs Clear Alarms & Logs
Clear Active Alarms x x
Clear Active Alarms
on page66
Clear Active Alarms
Clear the Alarm Log x x
Clear the Alarm Log
on page66
Clear the Alarm Log
Clear the Event Log x x
Clear the Event Log on
page66
Clear the Event Log
Table A.1 Guide to Liebert AC4 functions (continued)
A.2 Connecting to the Service Terminal Interface
This section describes how to set up and connect to the Service Terminal Interface. To access the Service
Terminal Interface, you will need:
• A null modem cable to connect a computer’s COM1 port to the Liebert AC4’s RS232 port.
• A communications program, such as HyperTerminal, to connect to the Service Terminal
Interface.
Refer to following sections for step-by-step instructions to set up a connection (one time) and use that
connection to access the Service Terminal Interface:
• Create a Connection on the facing page
• Connect to the Service Terminal Interface
The instructions in this section refer to the HyperTerminal program—they may vary for other
communications programs.
Vertiv | Liebert® AC4 User Manual | 70
