Liebert Hisp - Page 79

4
F i g . 1 d --- E v a p o r a t o r v e r s i o n w i t h o u t f r e e c o o l i n g S E 0 8 --- 1 0 --- 1 3 --- 1 4
U n i t à e v a p o r a n t e v e r s i o n e s e n z a f r e e c o o l i n g S E 0 8 --- 1 0 --- 1 3 --- 1 4
1100
105530 30
1086 12
12
1100
320 9032050
395
E
S
I
U
E
E
320
395
E
N.6 HOLES ø8
N.6 FORI ø8
F R O N T V I E W --- V I S T A F R O N T A L E
REAR VIEW --- VISTA POSTERIORE
conditioned air --- aria trattata
air return --- ripresa a ria
SIDE VIEW --- VISTA LATERALE
TOP VIEW --- VISTA DALL’ALTO
POS. Description --- Descrizioni
E Electrical connections --- Collegamenti elettrici
S Condensate drain --- Scarico condensa
U Refrigerant outlet --- Uscita refrigerante
I Refrigerant inlet --- Ingresso refrigerante
