3
F R O N T V I E W --- V I S T A F R O N T A L E
REAR VIEW --- VISTA POSTERIORE
Fig. 1c --- Condensing unit --- Unità condensante SC 05---06
SIDE VIEW --- VISTA LATERALE
TOP VIEW --- VISTA DALL’ALTO
I
E
U
770
285
15
800
537
AIR FLOW
FLUSSO ARIA
AIR FLOW
FLUSSO ARIA
15
N. 2+2 SQUARE CAGED NUTS M6
190 4042
N. 2+2 SQUARE CAGED NUTS M6
POS. Description --- Descrizioni
E Electrical connections --- Collegamenti elettrici
U Refrigerant outlet --- Uscita refrigerante
I Refrigerant inlet --- Ingresso refrigerante
