THE BLUE BOX LT PARTS REPLACEMENT & INSTALLATION GUIDE 57
1
7
6
2
3
5
4
3#18 AWG. Supplies power and neu-1.
tral from transformer to relay control
card.
14 conductor ribbon cable: carries
2.
control signal between DTC and relay
control card (master panel only).
2 conductor ribbon cable: carries con-
3.
trol signal from smacker strip to relays
- one per relay.
P10 conductor ribbon cable: carries
4.
digital signal from relay control card to
smacker strip
5 conductor ribbon cable: carries digital
5.
signal from relay control card to (op-
tional) digital input card
4#22AWG carries rs-232 signal from
6.
(optional) modem to relay control card
(master panel only) Dual-voltage (120V
or 277V)power supply.
Terminator / terminator pin-outs. (pro-
7.
vided inside master panel) - terminates
bus line.
1
2
4
10
5
6
7
8
9
6
2
3
Blue Box mounting holes (4).1.
Back plate mounting screws. (Retaining 2.
pin located at bottom, lift up and out to
remove)
RJ45 sockets for GR 2400 bus.
3.
Photocell input (master only). The Pho-4.
tocell may control any relay(s) in any
panel(s).
Optional modem. Analog phone line con-
5.
nects to RJ-12 socket.
Relays (line and load lugs).
6.
Dual-voltage (120V or 277V)power 7.
supply.
(Optional) Digital Input Card. [DI] 14
8.
(or 6 enable/disable) inputs.
Terminator pins. Terminate the bus only
9.
after the “System Start-Up and Cabling
Guide” has been completed.
Clock backplate and back of DTC clock
10.
(for the master panel only).
BLUE BOX LT 1416
