10.2 Button GO
The GO button 14 activates the SCU control panel.
After pressing button 14, the SCU control panel will remain active for 3 minutes.
To activate control panel:
Press button 14.
If no button has been pressed for 3 min:
Activate control panel again by pressing button 14.
10.3 Mute
To mute audio alarm signal:
Press button 10.
If cause of error signal is not remedied:
Audio alarm signal will switch back on after 30 min.
10.4 Pressure Control
When switched on, the SCU will inate the mattress to the recommended pressure. Once this pressure is rea- ched,
indicator 16 will stop ashing and remain solid on, and an audio signal will sound.
In order to guarantee optimum protection, the system adjusts the pressure automatically to the patient’s weight and posi-
tion every 7.5 minutes in APT mode.
Button/Indicator Function
Pressure Control Button Changing air pressure in mattress.
Mode Indicators Indicate selected mode:
APT Alternating Pressure Therapy
MAX Maximum Inate
CLP Constant Low Pressure
Mode Selection Button Selects desired mode.
Seat Mode Indicator Indicates that seat cushion is connected.
Backrest Status Indicator Indicates if backrest is raised.
CPR/Air Disconnected Indicator Indicates that air pipe is not connected correctly or not at all.
System Error Indicator Indicates system error.
Call service engineer.
Audio Mute Button Muting audio alarm signals.
Service Due Indicator Indicates that service is due.
GO Button Activates the control panel.
Battery Charge Status Indicator
(battery back-up model only)
Indicates charge status of battery.
Pressure Level Indicator Indicates air pressure set in mattress or seat cushion.
