1.3 Symbols and Labels on the Product
Read user manual
2x T1AH anti-surge fuse
(250 V, type 5x20mm)
2x T2AH anti-surge fuse
(250 V, type 5x20mm)
(model with battery back-up)
Alternating current
Activation GO button
Device is connected to mains if green indicator is lit
Protection against accidents due to electrical current – Type B instruments
Double isolation
Attention
CE mark of conformity with EU regulation
I
O
Mains Switch
I: ON (connected to the mains supply)
O: OFF (disconnected from mains supply)
Device is connected to mains when green indicator is on.
1.4 Serial Label
The serial label is located on the back of the SCU (System Control Unit). The serial number, the model number and the
voltage version can be found on the type plate. This information is required when contacting LINET®.
Fig. 1 Serial Label
