11.5 Head Zone Selector/Heel Zone Selector
If a head/heel zone selector is tted, it is possible to congure the head and heel section of the mattress for nursing pro-
cedures (e.g. prone positioning, intubation).
It permits setting each cell of the head or heel section separately to one of three (head zone selector) or one of two (heel
zone selector) modes.
1. Deated
2. APT
3. MAX
Toconguretheheadsection:
 Remove foot board of bed frame.
 Open ap on foot end of mattress cover.
 Select required setting with respective rotary control.
 Close ap on foot end of mattress cover.
Fig. 16 Head Zone
31 2
