12
Chapter 4: Using the Console Interface for Configuration
Connecting to the Switch through a Telnet Session
24-Port 10/100/1000 Gigabit Switch with Webview and PoE
4. Set the serial port settings as follows:
Bits per second: 38400
Data bits: 8
Parity: None
Stop bits: 1
Flow control: None
Then, click the OK button.
Connecting to the Switch through a Telnet Session
Open a command line editor and enter telnet 192.168.1.254. Then, press the Enter key.
The Login screen will now appear. The first time you open the CLI interface, select Edit and hit Enter. Enter admin
in the User Name field. Leave the Password field blank.
Press the Esc button and you will return to the login screen. Use the right arrow button to navigate to Execute
and press the Enter button to enter the CLI interface.
Figure 4-4: COM1 Properties
Figure 4-5: Telnet Login Screen
