23
Chapter 4: Using the Console Interface for Configuration
Configuring the Switch through the Console Interface
24-Port 10/100/1000 Gigabit Switch with Webview and PoE
ports and later the power demands on the Switch fall back within its budget, the dropped power is automatically
restored.
Port PoE Configuration
The Power Port Configuration screen allows you to set the PoE settings for each port. Select the Edit action and
use the left-right and up-down arrows to select the attribute you would like to set. You can set the Admin Status,
the Priority, and the Power Allocation for each port. Use the Save action to save the new settings.
Help
Select Help and press the Enter key if you want to view the help information. This screen explains how to
navigate the various screens of the console interface.
Log Out
Select Log Out to log out of the Console Configuration Utility.
Figure 4-28: Port PoE Configuration
Figure 4-29: Help
Figure 4-30: Log Out
