72
Chapter 5: Using the Web-based Utility for Configuration
Admin Tab - Log
24-Port 10/100/1000 Gigabit Switch with Webview and PoE
Enter the IP address and community string for each management station that will receive trap messages. Strings
are case-sensitive and can be up to 32 characters long. Specify the trap UDP port and version, then click Add.
Click Save Settings to save the changes.
Admin Tab - Log
The Switch allows you to configure and limit system messages that are logged to flash or RAM memory,
configure the logging of messages that are sent to remote System Log (Syslog) servers, and set an event-level
threshold for sending email alert messages to system administrators.
The following table describes the system event levels.
* There are only Level 2, 5 and 6 event messages for the current firmware release
System Logging
The system allows you to enable or disable event logging, and specify which event levels are logged to RAM or
flash memory. Severe error messages that are logged to flash memory are permanently stored in the Switch to
assist in troubleshooting network problems.
System Log Status. Enables/disables the logging of debug or error messages to the logging process. (Default:
Enabled)
Level* Severity Name Description
7 Debug Debugging messages
6 Informational Informational messages only
5 Notice Normal but significant condition, such as a cold start
4 Warning
Warning conditions, such as return false or unexpected
return
3 Error Error conditions, such as invalid input or default used
2Critical
Critical conditions, such as memory allocation, free
memory error, or resource exhausted
1 Alert Immediate action needed
0 Emergency System unusable
Figure 5-54: Admin - Log
