Lode BV Excalibur Sport
51
Contrast
contrast = 50%
esc ok
p-in/out analog
ECG START
Default startmenu
sett ok
ECG Start
ON
esc ↑ ↓ ok
Lode prot 38k4
ERGOLINE P1
Lode protocol
esc ok
Save
esc yes no defau
Only after confirmation with save the new contrast is kept.
Another extra option for the Programmable control unit in the menu SETTINGS is the ECG
START selection for the P-display.
Selecting ok shows.
Only after confirmation with save the new setting is stored. With this option a 400ms pulse is
generated 10 s. before the end of a protocol stage to an output on the ergometer. With this
output ECG apparatus without a digital interface can be started.
The Programmable control unit offers in the RS232 PROTOCOL sub menu of the SETTINGS
menu an extra choice for the ERGOLINE P1 protocol.
Selecting ok shows.
