2.7.3 Technical details
Table 2 shows the technical characteristics of the instrument.
Table 2. Technical data instruments of the series DLC
NET
Data
Value
Supply
24 Vdc ±10 %, with galvanic isolation between 24 Vdc, power supply of load cells
and Fieldbus
Power
3 W max
Maximum current
150 mA (max 4 load cells of 350 ohm)
Temperature range
from 0 °C to + 45 °C
Load cells power supply
5 Vdc
Input signal
from - 4 mV/V to + 4 mV/V
Weight resolution
19 bit + sign (524.288 divisions to 4 mV/V)
Maximum sensitivity
40 nV/div
Fieldbus
Profibus-DP
®
, Profinet
®
Linearity
0.01 % F.S.
Conversions
10 or 80 sample/s configurable (default 10)
Digital filter
8, 16, 32, 64 averaged values
Protection
IP20
Digital outputs (EB-board)
n. 8 output, 24Vdc 100mA total with all outputs on
Serial outputs
RS-485 and RS-232 (on EB-board)
Analog output (EB-board)
0-20mA – 4-20mA configurable
Dimensions
30 x 135 x 107 mm (W x H x D)
2.7.4 Operating
environment
The environmental license plate requirements for the correct functioning of the
instrument are:
↘ Operating temperature: 045°C
↘ Storage temperature: 050°C
↘ Humidity: 85% non-condensing
2.7.5 Electromagnetic
compatibility
The boards of DLC
NET
series are equipped with appropriate filtration in order to
meet the EMC requirements that the Directive 2014/34/EU requires.
To improve immunity to radiated interference, emitted by a radio transmitter,
it is important to:
↘ Use shielded cables with shielding connected to earth at 100% for
connections to the card.
↘ In the presence of earth resistance values low, connect to ground
both sides of the screen to improve the effectiveness of the
shielding.
