USE AND MAINTENANCE MANUAL – DLC

NET

Series

Use as a batcher

LOGIC S.r.l. - M0145Db.docx

Mod. L0006A01 of 30/05/2016

Page 72 of 78

 From the main menu, press the button to enter the print menu

( )

 Press to confirm, but press to cancel.

 If confirmed, the print will be sent automatically via the RS-232 serial port.

6.4.6 Abort of recipe

( )

If there is any malfunction, it is possible to abort a recipe.

To abort a recipe follow the procedure below:

 Press the buttons and simultaneously

 The display will show

 The printer memory is erased, all the leds are turned off and you can start

a new recipe.

If you make abort during a dosage of automatic components, put before

pause by pressing .
