19. When you have rotated the log the last time to cut the last boards, you have to calculate where you should
take the cut to make the last cut agree with the calculation. Check this by lowering the blade until it rests
against the log. Now you can read the absolute scale to see the amount of wood left under the blade. Set
the sawhead to the desired height.
TIP
The easiest way is to wait to rotate the log until there only remains material for one 2’’
board. If you do so, there is no need for calculation.
HANDLING SAWN TIMBER
When cutting the cant into boards, you can either immediately lift the boards off the cant, or you can leave
them there while cutting more boards before handling the timber.
When you are going to lift boards from the rails, ensure that the saw carriage is in its locked position at one
of the rail ends. Then, move the sawn timber to a timber stack. Place spacers between the layers of boards to
facilitate drying.
USER MANUAL
106
