www.longer3d.com support@longer3d.com
9
2.3. Install holders of filament and sensor
Use M3x12 screws to fix the filament sensor holder, and use M5x16
screws to fix the filament holder.
Filament Sensor Holder
Filament holder
2 PCS M5X16 screw
2 PCS M3X12 screw
M5X16
M3X12
