35
SD 320_2 05/2015
4. Operation
4.1 Display elements
1. Main display: Conductivity (mS/cm, µS/cm)
specific resistance (kΩcm,
MΩcm) TDS, Total Dissolved
Solids (mg/l), salinity (SAL)
2. Secondary display: Temperature measure-
ment value
3. Temperature measurement value
4. Battery status
5. Display elements representing the minimum/
maximum/saved measurement
6. nLF NaCl,
display of the selected
Lin: Temperature compensation
7. %/K,
additional
1/cm: configuration units
8. logg-Pfeil:
Logger is active.
Arrow blinks: automatic
storage
(Logg CYCL) is active.
4.2 Controls
On/Off switch, light
Press briefly: Activate light and/or switch
on device
Press and hold:
Switch off device
set / menu:
Press briefly: Change unit in display (if “InP: Set“)
Press and hold for 2 sec. (Menu): Open the
set-up menu.
min / max:
Press briefly: Display of the minimum and/or
maximum measured value
Press and hold for 2 sec.: Deletion of the re-
spective value
cal: Only in 'cond' operating mode:
Press and hold for 2 sec.: Cell constant calibration
store / enter:
In case of
logger
function: off: Hold and save of the current
measurement ('HLD' in display)
In case of
logger
function: on: Operation of the data logger -
Data logger chapter
Set/Menu: Confirmation of entries, return to
measurement
4
3
1
5
2
MAX
°C
°C
°F
HLD
DIF MIN
6
7
8
nLF NaCl Lin % 1 Logg
K cm
kΩ•cm MΩ•cm mS µS mg
cm cm l SAL
Con
2
