Lovibond SD 320 Con User Manual

36
SD_320_2 05/2015
4.3 Connections
Universal output: Interface, supply, analogue
output (see chapter 9.1, 9.2 Universal output)
7-pin bayonet connection: Connection for
electrode / measuring cell and temperature
sensor
4.4 Stand/ Mounting
Operation:
Stand-up hinge folded in. Device Fold out the stand-up hinge.
can be hung on a belt.
Device set up Pull out at the Device hung on
on a table. "open" marking to fold on a screw.
the stand-up hinge out again.
Pull
