Accuracy Conductivity ± 0.5% of reading
± 0.1% FS (depends on electrode)
Temperature ± 0.2 K
Add. functions Min/Max/Hold
Calibration of cell constants manually or automatically using
selectable reference solutions
GLP Adjustable calibration intervals (1 to 730 days, CAL
warning after lapse)
Calibration memory: lasts 16 calibrations
Data logger Real time clock
Cyclical: 10.000 data sets, variable cycle:
1s - 60 min
Single: 1000 data sets, with measurement point entry
and date + time
Alarm 2 alarm channels with separate thresholds for
conductivity (and/or resistance, TDS, SAL) and
temperature
Alarm audio/visual/interface
Housing Break-proof PA6 GB30 housing, incl. protective
reinforcement
Protection class IP65 / IP67
Dimensions
L x
W x
H [mm]
164 x 128 x 37 incl. protective reinforcement,
approx. 250 g incl. battery and protective
reinforcement
Operating conditions -25 to 50 °C; 0 to 95 % r.h. (non condensing)
Storage temperature -25 to 70 °C
Power supply 2
.
AAA batteries, (included in the scope of delivery)
or external
power con-
sumption
6.25 mA (with Out = Off, corresponding to 160 h),
lighting ~10 mA (switches off automatically)
Battery dis-
play
4-stage battery status display,
Change display with depleted battery "bAt"; "bAt"
blinking = warning
Auto-Off function If activated, the device switches off automatically
when not used for an extended period of time
(variable 1 - 120 min)
EMC The device corresponds to the essential safety
requirements, which are defined in the Council
Directive for the harmonisation of the legal
requirements of the Member States over
electromagnetic compatibility (2004/108/EC).
Additional error: <1%
*)The selection of the electrode can diminish the actual range of application, although
additional display range is theoretically provided by the device. See Chapter 6.7
