8-20
Used when an inverter operates 2 motors connected to two different types of the loads.
2
nd
motor operation does not drive 2 motors at the same time.
As the figure below, when using two motors with an inverter by exchanging them, select one
motor from 2 motors connected. When 1
st
selected motor operation is stopped, select a
terminal for 2
nd
motor and define H81-H90 parameters to drive the 2
nd
motor.
Define the 2nd motor select when a motor is stopped.
H81 ~ H90 parameters function the same as 1
st
motor.
IM 1
IM 2
iG5+
P8
IG5A
