8.11 Speed search
Group Display Parameter Name Setting Range Default Unit
Function
group 2
H22 [Speed search select] -
0 ~ 15 0
H23 [Current level] - 80 ~ 200 100 %
H24 [Speed search P gain] -
0 ~ 9999
100
H25 [Speed search I gain] - 200
I/O group I54
[Multi-function output
terminal select]
15
0 ~ 18
12
I55 [Multi-function relay select] 15 17
 This is used to prevent possible fault from occurring if the inverter outputs the voltage
during operation after the load is removed.
 The inverter estimates the motor rpm based on output current. Therefore, detecting exact
speed is difficult.
The following table shows 4 types of Speed search selection.
H22 Speed search
during H20 –
[Power ON start]
Speed search
during Instant
Power Failure
restart
Speed search
during H21-
[Restart after
fault reset]
Speed search
during
Acceleration
Bit 3 Bit 2 Bit 1 Bit 0
0 - - - -
1 - - -
9
2 - -
9
-
3 - -
9 9
4 -
9
- -
5 -
9
-
9
6 -
9 9
-
7 -
9 9 9
8
9
- - -
9
9
- -
9
10
9
-
9
-
11
9
-
9 9
12
9 9
- -
13
9 9
-
9
14
9 9 9
-
15
9 9 9 9
 H23: Limits current during Speed search. Set as the percent of H33.
 H24, H25: Speed search is activated via PI control. Adjust P gain and I gain corresponding to
the load characteristics.

 I54, I55: Signal of active Speed search is given to external sequence via Multi-function output
