3-3
3.3 Recommendable Fuse, Reactors
Inverter Capacity
AC Input fuse [External Fuse]
AC Reactor DC Reactor
Current Voltage
004iG5A-1 10 A 500 V 4.20 mH, 3.5A -
008iG5A-1 10 A 500 V 2.13 mH, 5.7A -
015iG5A-1 15 A 500 V 1.20 mH, 10A
004iG5A-2 10 A 500 V 4.20 mH, 3.5A
008iG5A-2 10 A 500 V 2.13 mH, 5.7A
015iG5A-2 15 A 500 V 1.20 mH, 10A -
022iG5A-2 25 A 500 V 0.88 mH, 14A -
037iG5A-2 30 A 500 V 0.56 mH, 20A -
040iG5A-2 30 A 500 V 0.56 mH, 20A -
055iG5A-2 30 A 500 V 0.39 mH, 30A -
075iG5A-2 50 A 500 V 0.28 mH, 40A -
110IG5A-2 70 A 500 V 0.20 mH, 59 A 0.74 mH, 56 A
150IG5A-2 100 A 500 V 0.15 mH, 75 A 0.57 mH, 71 A
185IG5A-2 100 A 500 V 0.12 mH, 96 A 0.49 mH, 91 A
220IG5A-2 125 A 500 V 0.10 mH, 112 A 0.42mH, 107 A
004iG5A-4 5 A 500 V 18.0 mH, 1.3A -
008iG5A-4 10 A 500 V 8.63 mH, 2.8A -
015iG5A-4 10 A 500 V 4.81 mH, 4.8A -
022iG5A-4 10 A 500 V 3.23 mH, 7.5A -
037iG5A-4 20 A 500 V 2.34 mH, 10A -
040iG5A-4 20 A 500 V 2.34 mH, 10A -
055iG5A-4 20 A 500 V 1.22 mH, 15A -
075iG5A-4 30 A 500 V 1.14 mH, 20A -
110IG5A-4 35 A 500 V
0.81 mH, 30 A 2.76 mH, 29 A
150IG5A-4 45 A 500 V
0.61 mH, 38 A 2.18 mH, 36 A
185IG5A-4 60 A 500 V
0.45 mH, 50 A 1.79 mH, 48 A
220IG5A-4 70 A 500 V
0.39 mH, 58 A 1.54 mH, 55 A
z Short Circuit Rating
“Suitable For Use ON A Circuit Capable Of Delivering Not More Then 65KA
Symmetrical Amperes. 240V drives or 480V drives Volts Maximum,”
z Short Circuit FUSE/BREAKER Marking
Use Class H or K5 UL Listed Input Fuse and UL Listed Breaker Only. See the table above For
the Voltage and Current rating of the fuse and the breaker
