8-22
The following table shows the fault type while this function is active.
No. Display Fault type Diagnosis
1
UPHF
Switch above IGBT’s U phase fault Contact LSIS sales
representatives.
2
UPLF
Switch below IGBT’s U phase fault
3
vPHF
Switch above IGBT’s V phase fault
4
vPLF
Switch below IGBT’s V phase fault
5
WPHF
Switch above IGBT’s W phase fault
6
WPLF
Switch below IGBT’s U phase fault
7
UWSF
Output short between U and W Check for the short of inverter
output terminal, motor
connection terminal or the
proper motor connection.
8
vUSF
Output short between U and V
9
WvSF
Output short between V and W
10
UPGF
Ground fault at U phase Check for the ground fault
occurred at inverter output
cable or motor or motor
insulation damage.
11
vPGF
Ground fault at V phase
12
WPGF
Ground fault at W phase
13
UPOF
Output open at U phase Check for proper connection of
the motor to the inverter output
or proper motor connection.
14
vPOF
Output open at V phase
15
WPOF
Output open at W phase
8.16 Frequency setting and 2
nd
drive method select
Group Display Parameter Name Setting Range Default Unit
Drive
group
drv Drive mode 1 - 0 ~ 3 1 -
Frq Frequency mode 1 - 0 ~ 8 0 -
drv2 Drive mode 2 - 0 ~ 3 1
Frq2 Frequency mode 2 - 0 ~ 7 0
I/O
group
I17~I24
Multi-function input
terminal P1 select
-
0 ~ 27
Drive mode 1 is used when the input set as 2
nd
source is not entered into multi-input
(I17~I24)
Drive mode 2 can input frequency setting and drive command as a 2
nd
setting value by
using multi-input terminal. In case of driving away from inverter by communication, it is
used when quit the communication and operate by inverter.
The switching method for Drive mode 1 and Drive mode 2 is as follows
If multi-input terminal set as Drive mode 2 is off, it used as Drive mode 1. If multi-input
terminal set as Drive mode 2 is on, it used as Drive mode2.
Selects the self drive in the 2
nd
switching of drv2 among the followings
drv2
Drive mode 2
0 Operation via Run/Stop key on the Keypad
1
Terminal
operation
FX: Forward Run command
RX: Reverse Run command
2
FX: Run/Stop command
RX: Forward/Reverse command
3 Operation via communication
